Monitor electricity, water, gas, chillers, VRV, compensation and charging stations on one screen — together with distribution company, EPİAŞ and hospital information system data.
What does it do? Collects data from electricity, water and gas meters, transformers, UPS, chillers, VRV units and sensors into one dashboard; prevents reactive penalties, peak overshoot, leaks and energy losses.
Who is it for? Multi-site facilities like hospitals, malls, factories, industrial zones and solar plants; energy managers and technical directors.
How does it work? The on-site Field Agent reads devices via Modbus, M-Bus and BACnet and sends them to the cloud over encrypted MQTT; charging stations connect over OCPP, distribution company and EPİAŞ data is linked directly — zero data loss.
Seamless data flow from field to cloud, in 4 steps.
A software agent installed on-site reads energy analyzers, transformers, UPS, and generators via industrial protocols at regular intervals.
Readings are transmitted encrypted to the central server. Even if internet is cut, data is buffered locally for at least 30 days and auto-synced when reconnected.
Incoming data is analyzed; hourly and monthly summaries are generated, reactive penalty is calculated, alarm rules are evaluated, and billing runs automatically.
Live monitoring, trend charts, invoice comparison, projection reports, and alarm notifications — all in one secure web interface.
From electricity to water, from chillers to charging stations, from distribution companies to hospital information systems — each module works independently; pick what you need.
kWh, kW/kVA/PF and day/peak/night analysis; transformer load ratio, losses and temperature alarms.
Details →Battery, autonomy and bypass status; generator start logs, engine hours and DSE protocol.
Details →Capacitor stage and relay tracking; warns before inductive/capacitive ratios reach the penalty limit.
Details →Phase imbalance, THD, voltage deviation and CT polarity fault detection.
Details →Gross solar plant output and its netting against energy drawn from the grid.
Main and sub-meter m³ tracking from M-Bus and Modbus water meters, by block and unit.
Details →Catches leaks before the bill arrives using night base flow and main-vs-sub meter gaps.
Details →Hourly/daily Sm³ and thermal kWh tracking from the distribution company's main meter reading.
Details →Chiller temperature, load and fault tracking; rule-based setpoint writes within safe bounds over a signed channel.
Details →Run state, mode, temperature and fault status of hundreds of indoor and outdoor units over BACnet/IP.
CO₂ / indoor air quality, window contacts and room controllers; battery, tamper and communication alarms.
Charging session, energy and power tracking over OCPP 1.6-J / 2.0.1; remote start/stop and power limit.
Details →Official meter readings are pulled automatically from distribution portals such as BEDAŞ OSOS and İGDAŞ AVE and fed into invoice reconciliation.
Details →Hourly market clearing price and YEKDEM are used to compute free-consumer electricity cost hour by hour.
Details →Room/bed occupancy is read; consumption is normalised by occupancy and passed to the BMS over Modbus.
Details →Hourly temperature and seasonal outlook; consumption is weather-normalised and feeds the budget forecast.
Details →Two-way data with the existing BMS over Modbus/BACnet; equipment is tied to energy and cost.
Details →Month-end projection anchored on the measured series; weather and occupancy effects separated, budget variance refreshed daily.
Details →Day/peak/night tariff, reactive penalty, TRT/BTV/VAT included; reconciliation with the official invoice and sub-tenant billing.
Details →Energy, power systems, water, HVAC and sensor alarms; mail-storm protection and daily digest.
Details →Maintenance advice before faults grow, from chiller performance decline, flapping faults and leak trends.
Scope 1–2 emissions from electricity and gas consumption, with year-over-year comparison.
Details →EnPI variable catalogue, regression analysis, climate-normalised consumption and an auditor-ready Excel report.
Details →Daily digest, monthly management/board report and HVAC report delivered automatically by email.
6S Teknoloji is a SaaS-based energy management platform that reads transformers, UPS, generators and energy meters in industrial facilities continuously via Modbus TCP/RTU, M-Bus, BACnet/IP and MQTT protocols, providing single-screen monitoring, automatic budget projection and EPDK-compliant reporting. On the reporting side the daily digest, the monthly management report and invoice reconciliation are produced automatically; on the automation side, closed-loop actions such as rule-based chiller setpoint writes are executed and logged.
| Feature | Value |
|---|---|
| Data Collection | Configurable field reads; hourly and daily summaries |
| Protocols | Modbus TCP/RTU, M-Bus, BACnet/IP, OCPP 1.6-J/2.0.1, LoRaWAN, MQTT, DSE |
| Offline Buffer | 30 days (local buffer) |
| Live Data Retention | 13 months (hourly/daily summaries kept indefinitely) |
| Device Template | Ready-made template library + custom register map |
| Device Independence | Brand-independent (Modbus/M-Bus/BACnet/OCPP/SNMP/DSE) |
Multi-site portfolio: electricity, water and gas consumption is measured site by site and compared on a single portfolio screen. Budget variance is tracked separately for each site, and the management summary report is emailed automatically at month end.
Explore the system with your own data in a demo session.
